Dry wipe Noticeboard

Product Code:
Dry wipe Noticeboard

Technical specification of product Dry wipe Noticeboard

Technical
Packing unit height (mm) 1614 | 790 | 1090 | 1279 | 931 | 684 | 510 | 387 | 1106 | 1768
Packing unit length (mm) 33
Packing unit width (mm) 1106 | 590 | 790 | 931 | 684 | 510 | 387 | 300 | 725
Length (mm) 33
Width (mm) 1106 | 598 | 590 | 790 | 852 | 931 | 684 | 510 | 387 | 300 | 725 | 1290
Height (mm) 1614 | 852 | 790 | 1090 | 1106 | 1279 | 931 | 684 | 510 | 387 | 1360 | 1768 | 1890
Dimensions summary (mm) 1106 x 1614 x 33 mm | 598 x 852 x 33 mm | 590 x 790 x 33 mm | 790 x 1090 x 33 mm | 852 x 1106 x 33 mm | 931 x 1279 x 33 mm | 684 x 931 x 33 mm | 510 x 684 x 33 mm | 387 x 510 x 33 mm | 300 x 387 x 33 mm | 725 x 1106 x 33 mm | 1106 x 1360 x 33 mm | 1106 x 1768 x 33 mm | 1290 x 1890 x 33 mm
Net weight (kg) 15.71 | 6.04 | 6.8 | 9.08 | 8.09 | 11.48 | 7.43 | 4.74 | 3.39 | 2.8 | 8.66 | 13.59 | 17.6 | 19.96
Total weight (kg) 18.51 | 7.05 | 6.8 | 10.55 | 9.72 | 13.45 | 8.61 | 5.5 | 3.92 | 3.2 | 10.09 | 15.99 | 20.79 | 23.65
Corners type Mitred
Color Silver
Material Aluminium / Plastic
Own brands possibility Yes | No
Fixation Screws
Door Yes
Doors number of locks 2 | 1
Doors lockable Yes
Doors padding PETG 3 mm
Installation Wall
Visible size (mm) 1000 x 1508 | 492 x 746 | 484 x 684 | 684 x 984 | 746 x 1000 | 825 x 1173 | 578 x 825 | 404 x 578 | 287 x 404 | 194 x 281 | 619 x 1000 | 1000 x 1254 | 1000 x 1662 | 1184 x 1784
Front panel PETG 3 mm
Rear panel Metal back

  • These wall mounted lockable noticeboards feature a robust 53mm wide silver anodised aluminium frame profile.

    • High Impact 3mm clear PETG front panel with tape sealed edge
    • Dry wipe magnetic rear panel on all sizes except SCPXE1016x1524
    • SCPXE1016x1524 is only magnetic and not dry wipe
    • 16mm internal depth to hold posters away from the front panel
    • Deeper frame construction helps to prevent condensation inside
    • Silicon rubber gasket to hinged front panel and metal back panel
    • Unique hinged magnetic poster capture rails to top and bottom
    • Silver anodised finish as standard. RAL painted colours on request
    • Suitable for covered outdoor use
    • Wall mount use only - not suitable for fence, railing or post fix application
    • Outdoor lockable poster case and magnetic noticeboard combination design
    • 2 keys per lock
    • A1 sizes and above come with 2 locks to the door
The product is no longer on offer
