Jansen Display
Outdoor light box SCT LED 70x100
Product Code:
SCTL70x100PH
Downloads:
Safety Instructions - GPSR (74kB)
Technical specification of product Outdoor light box SCT LED 70x100
| Technical | |
| Assembled product | |
| Assembled product weight (kg) | 23.6 |
| Assembled product width (mm) | 816 |
| Assembled product depth (mm) | 55 |
| Assembled product height (mm) | 1116 |
| Packaging unit | Piece |
| Weight (kg) | 25.93 |
| Width (mm) | 887 |
| Length (mm) | 1272 |
| Height (mm) | 102 |
| Packaging unit | Pallet |
| Number of pieces | 7 |
| Weight (kg) | 206 |
| Width (mm) | 800 |
| Length (mm) | 1200 |
| Height (mm) | 1416 |
| Version | Single sided use |
| Warranty (m) | 12 |
| Corners type | Mitred |
| Electrical energy | Yes |
| Voltage (V) | 100-240V / 12V |
| Wattage | 32,3 W |
| Illumination | Yes |
| Lighting colour | +/- 5000K |
| Lighting source | LED light source |
| Cord length (m) | 2000 |
| Colour | Silver |
| Material | Aluminium / Metal / Glass |
| Own brands possibility | Yes |
| Fixation | Screws |
| Door | Yes |
| Doors lockable | Yes |
| Doors padding | Glass ESG 4 mm |
| Installation | Wall |
| Product certifications | IP56 |
| Visible size (mm) | 689 x 989 mm |
-
- Premium Lockable Outdoor LED illuminated poster case
- 63mm wide aluminium frame with LED illuminated laser dot panel
- Top hinged opening front with 4mm clear toughened safety glass
- A3, A2, A1, A0, 20"x 30", 30"x 40" & 40"x 60" Portrait poster sizes
- Metal support bar holds front open on A2, A1, B2, B1, 20"x30", 30"x40"
- Quality gas strut opening on A0, 1000x1400mm and 40"x60" sizes
- IP56 certified for outdoor weather resistance and high performance
- Silver anodised finish as standard. RAL painted finishes on request
- Individually boxed with low voltage power adapter with UK/EU plug
- The power supply must be remotely housed - not within the light box
Please select a combination of products :
Upload a poster print theme
Drag the file from your computer
or
Rules for uploading files
- Supported image formats: .PDF, .JPG, .PNG
- maximum size up to 2GB
Upload a poster print theme
Drag the file from your computer
or
Rules for uploading files
- Supported image formats: .PDF, .JPG, .PNG
- maximum size up to 2GB
- £659.65 Ex Tax
- Inc Tax £791.58
+
-
-
